X-Over 2-3/8" NPT Pin X 2-7/8" EUE Box

Products Mode: X-Over 2-3/8"
Place of Origin: Made in China
Material: J55,N80,L80,P110
Application: downhole tools connection
Standard: API 5B


Tianjin Forwell mainly produce the X-Over 2-3/8" NPT Pin X 2-7/8" EUE Box as per the latest API55CT and API5B specfication.

The Tinajin forwell X-Over can be divided into screw male female conversion, such as pin * pin (double male thread), pin * box (one male thread and one female thread), Box * box (double female thread). Different thread conversion, eue * nue, eue * if, nue * if, eue * NPT, nue * NPT, etc. With the same diameter and different diameter, it can be used in various forms, usually in products with different diameters and different threads at both ends of the joint,the manufacturer is Tianjin forwell energy equipment..

Product steel grade: J55, K55, N80, l80-1, l80-3cr, l80-9cr, l80-13cr, P110, 13cr-110, etc

Tubing joint specification: 1.315 "/ 1.9" / 2-3 / 8 "/ 2-7 / 8" / 3-1 / 2 "/ 4" / 4-1 / 2 "

Specification of casing joint: 4-1 / 2 ", 5", 5-1 / 2 ", 6-5 / 8", 7 ", 7-5 / 8", 8-5 / 8 ", 9-5 / 8", 10-3 / 4 ", 13-3 / 8" (114.3-339.7) m
